Tapered Cov Menyuam Thawm Cov Kabmob
Tapered rau cov kabmob thom kabmob lub tshuab ntxhua khaub ncaws thiab cov menyuam thiab sib sib zog nqus sib sib zog nqus tau sib txuas tau. TEDIN's tapered roller thrust bearings muaj qhov zoo li hauv qab no:
Qis kev sib txhuam:
Qhov kev xav ntawm tus flange tsim ntawm tus flange thiab qhov fais fab ntawm qhov flange yuav txhawb kev tsim cov roj nplua nyeem thiab txo cov kev sib txhuam. Qhov no kuj txog lub tshav kub tau los ntawm txhuam thiab flange hnav.
Kev pab lub neej ntev:
Nyob ntawm tus qauv tsim, piv nrog cov racrid conventional, lub rooj sibtham lossis raceway logarithmic raceways tuaj yeem kho qhov kev faib khoom ntawm qhov sib chwv, txo qhov ncov siab ncov kawg ntawm tus menyuam, thiab txo qhov kev zoo siab rau qhov kev coj tsis ncaj.
Zoo sib xws ntawm qhov profile thiab qhov me me ntawm chais:
Lub hau kev raug rau siab thiab qhov sib luag ntawm qhov sib luag hauv TEDIN tapered roller thrust bearings yog li ntawd tias lawv yuav luag zoo tib yam. Qhov no muab qhov siab tshaj plaws kev faib khoom kom txo tau cov suab nrov thiab kev sib tw thiab kom ua tiav ntau dua.
Ciam qhov ntev | Yooj yim peev txheej | Kev tsim | Pawg | ||||||
hli | kN | Tam sim no | Thawj | kg | |||||
D | D1 | d1 | T | R | rmin | Coa | |||
150 | 148 | 127 | 48 | 228,6 | 1.5 | 1630 | TTSV150 | 4297/150 | 5 |
175 | 173 | 152 | 53 | 228,6 | 1.5 | 2180 | TTSV175 | 4297/175 | 8 |
203 | 201 | 178 | 65 | 254 | 1.5 | 2540 | TTSV203 | 4297/203 | 11 |
205 | 203 | 178 | 65 | 254 | 1.5 | 3370 | TTSV205 | 4297/205 | 15 |
235 | 233 | 208 | 73 | 280 | 1.5 | 3370 | TTSV235 | 4297/235 | 18 |
265 | 263 | 229 | 81 | 304.8 | 1.5 | 4130 | TTSV265 | 4297/265 | 24 |
320 | 318 | 280 | 95 | 380 | 1.5 | 7370 | TTSV320 | 4297/320 | 42 |
377 | 375 | 330 | 112 | 457.2 | 2.5 | 8230 | TTSV377 | 4297/377 | 86 |
380 | 378 | 330 | 112 | 457.2 | 1.5 | 8220 | TTSV380 | 4297/380 | 67 |
410 | 408 | 355 | 122 | 508 | 3 | 11300 | TTSV410 | 4297/410 | 115 |
440 | 438 | 380 | 130 | 508 | 3 | 18500 | TTSV440 | 4297/440 | 140 |
495 | 492 | 432 | 146 | 558.8 | 3 | 19100 | TTSV495 | 4297/495 | 198 |
525 | 522 | 460 | 155 | 635 | 3 | 20380 | TTSV525 | 4297/525 | 210 |
555 | 552 | 482 | 165 | 635 | 3 | 21380 | TTSV555 | 4297/555 | 275 |
580 | 577 | 510 | 165 | 710 | 3 | 23540 | TTSV580 | 4297/580 | 250 |
610 | 607 | 533 | 178 | 762 | 3 | 24170 | TTSV610 | 4297/610 | 350 |
640 | 637 | 550 | 185 | 762 | 3 | 28670 | TTSV640 | 4297/640 | 410 |
